DongXu Skeleton Trailer / Skeletal Trailer / Container Chassis Trailer Manufacturer Customized OEM/ODM Supplier

DongXu, the semi trailer specialist in China. AS the leading semi trailer manufacturer and OEM/ODM supplier in China, we provide perfect customized service for customers, and also provide the optimal solutions for land transporting. DongXu Skeleton Semi Trailer is one of the core products of DongXu semi trailer series, which is mainly used in the field of container transport. According to customers‘ needs, various configurations can be provided to meet customers’ transport requirements.

Trailer Name: Skeleton Trailer

Trailer Type: Semi Trailer

Tare Weight: About 7.1T

Max Payload: More Than 30 Tons

Size: 12500mm*2500mm*1500mm 2/3 axles for 40ft container

     6200mm*2500mm*1500mm 2 axles for 20ft container

Axle: 2/3 Axle 13T/16T Fuwa Brand

Suspension: Mechanical Suspension / Air Suspension

Landing Gear: JOST Brand D200T / Chinese Brand 28T

King Pin: JOST 2″(50mm) or 3.5″(90mm)

Twist Lock: 4-12 Sets

Tire: 9/13 Units, 12R22.5 or 315/80R22.5

Rim: 9.00-22.5 or 9.75-22.5

Spring Leaf: 90mm(W) x 13mm x 10Layers / 100mm(W) x 12mm(T) x 12Layers

Brake Chamber: WABCO RE6 Relay Valve

Main Beam: Height500mm, Upper14mm, Middle8mm, Bottom16mm, Q345B Steel.

Painting: Sandblasted, Anti-rust Chassis Surface With 1 Layer of Anti Corrosive Primer and 2 Layers of Top Coats.

Function: 20’ 40’ Container Transporting

All the parts can be customized as your requirements.
