Dong Xu Cement Bulker Trailer is suitable for transporting and pneumatic unloading of dry materials such as fly ash, cement, lime powder, ore powder with a particle diameter of no more than 0.1mm. When the vertical height of the unloading reaches 15m, the horizontal conveying distance can reach 5m.
  • BrandDONG XU
  • Product OriginChina
  • Delivery Time10 Working Days
  • Supply CapacityFactory Direct Supply

Cement Bulker TrailerCement Bulker TrailerCement Bulker Trailer

Dong Xu Cement Bulker Trailer

Suitable for transporting and pneumatic unloading of dry materials such as fly ash, cement, lime powder, ore powder with a particle diameter of no more than 0.1mm. When the vertical height of the unloading reaches 15m, the horizontal conveying distance can reach 5m.

The integrated tank body has the characteristics of high overall strength, good rigidity, good pressure bearing, and good performance.

The tank adopts a single V or double V inward-inc limed horizontal structure, with double-pipe air intake and double-cylinder feeding.making the um-loading efficiency as high as 1.4 tons/min; the tank has high volume utilization and the ash remaining rate is as low as 0.2%.

Shandong Dong Xu Vehicle Co., Ltd., as a manufacturer, we can provide customized service as your requirements. And also, OEM/ODM service.

Product nameCement Bulker Trailer
TypeSemi-Trailer
Max Payload>30000 kg
Size13000*3000*1760mm
King pin2″(50mm)or3.5″(90mm)
Leaf Spring90(W)mm*13(Thickness)mm*10(Layer)
Landing GearJOST/FUWA/Yahua Brand 28T
Axle13 Ton Fuwa Brand
SuspensionMechanical Suspension/ Air Suspension
Tire12r22.5
Capacity25m3-60m3
Rim9.00-22.5
MaterialSteel
FunctionTransport cement, lime powder, ore powder or other a particle diameter of no more than 0.1mm.

PS: All the parts of trailer can be customized.
